Jeep Compass I (2006-2010) front wiper high speed control output Wiring diagram

12 11 CAN B BUS (+) CAN B BUS (-) B(+) BLK WIRE BRN WIRE BRN/DK BLU WIRE BRN/LT BLU WIRE BRN/TAN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B BUS (+) CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE ELECTRONICS FRONT WASHER PUMP MOTOR CONTROL FRONT WIPER HIGH SPEED CONTROL OUTPUT FRONT WIPER LOW SPEED CONTROL OUTPUT FRONT WIPER MOTOR (CENTER OF COWL PANEL) FRONT WIPER PARK SWITCH SENSE FUSE 17 FUSED B(+) (I.O.D) GROUND GRY WIRE HI SPD CTRL OUT HOT AT ALL TIMES IGN SW OUT IGNITION SWITCH OUTPUT (RUN-ACC) FUSE 16 IGNITION SWITCH OUTPUT (RUN-START) LIN BUS LO SPD CTRL OUT LT BLU WIRE LT GRN WIRE ORG/ WIRE PARK SW SENS PNK WIRE REAR WASHER PUMP MOTOR CONTROL REAR WIPER MOTOR (CENTER OF LIFTGATE) REAR WIPER MOTOR CONTROL RED WIRE STEERING CONTROL MODULE (AT STEERING COLUMN) TAN WIRE TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT) WHT WIRE WHT/DK GRN WIRE WHT/ORG WIRE WHT/PNK WIRE WINDSHIELD WASHER PUMP (RIGHT FRONT INNER FENDER ATTACHED TO WASHER RESERVOIR) WIPER MOTOR CTRL YEL WIRE
