Jeep Compass I (2006-2010) front can fog lamp control Wiring diagram
This page shows the only wiring diagram for the component.front can fog lamp control, which is found in the car Jeep Compass I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front can fog lamp control (1 of 1)
B(+)
BLK WIRE
CLUSTER
COMPUTER (LEFT DATA LINES SIDE OF SYSTEM INSTRUMENT PANEL)
COMPUTER LEFT DATA LINES FRONT SYSTEM FOG LAMP
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONICS
FRONT CAN FOG LAMP CONTROL
FRONT FUSE 17 FOG LAMP CONTROL OUTPUT
FUSE 33
FUSED B (+)
FUSED LIN B(+) BUS (I.O.D)
GRY WIRE
HIGH BEAM LAMP
HOT AT ALL TIMES
LEFT HEADLAMP
LEFT HIGH BEAM OUTPUT
LEFT LOW BEAM OUTPUT
LIN BUS
LIN GROUND BUS
LOW BEAM LAMP
LOW BEAM LAMP HIGH BEAM LAMP
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK BRK SW SNS
PNK WIRE
RED WIRE
RIGHT CAN HIGH BEAM BUS BUS OUTPUT OUTPUT (+) (-)
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT LOW BEAM OUTPUT
STEERING CONTROL MODULE (AT STEERING COLUMN)
VIO WIRE
WHT WIRE
WHT/DK GRN WIRE
WHT/ORG WIRE
WHT/PNK WIRE
YEL WIRE
Go to component -> Headlights circuit -> FRONT CAN FOG LAMP CONTROL
