Jeep Compass I (2006-2010) electric rear heated wiper backlite motor Wiring diagram
This page shows the only wiring diagram for the component.electric rear heated wiper backlite motor, which is found in the car Jeep Compass I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electric rear heated wiper backlite motor (1 of 1)
AT DRIVER'S SEAT)
BASE
BLK WIRE
BRN WIRE
CLUSTER
COMPASS MODULE
DATA LINK CONNECTOR
DRIVER DRIVER OUTSIDE DOOR REARVIEW LATCH MIRROR
DRIVER POWER MIRROR WINDOW SWITCH SWITCH
ELECTRIC REAR HEATED WIPER BACKLITE MOTOR
HANDS FREE MODULE
HIGH LIFTGATE MOUNTED DOOR STOP LATCH LAMP
INSIDE REARVIEW MIRROR
LEFT HEATED SEAT SEATS CUSHION HEATER MODULE
LEFT REAR TIRE PRESSURE TRANSPONDER
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER DOOR LATCH
PASSENGER OUTSIDE REARVIEW MIRROR
PATRIOT COMPASS
RADIO
SENTRY KEY REMOTE ENTRY/WCM MODULE
STEERING CONTROL MODULE
SUNROOF MOTOR
TRAFFIC INFORMATION RECEIVER MODULE
TRANSMISSION SOLENOID/ PRESSURE SWITCH ASSEMBLY
W/ HEATED MIRRORS
W/ HEATED SEATS
W/O HEATED MIRRORS
W/O HEATED SEATS
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> ELECTRIC REAR HEATED WIPER BACKLITE MOTOR
