Jeep Compass I (2006-2010) drv seat belt sw sns Wiring diagram

7 6 1 CAN B BUS (-) CAN B BUS (+) IGN SW SNS AJAR SW SNS BASE BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE FLUID LEVEL CAN B SW SNS BUS (+) BRAKE FLUID LEVEL SENSOR BRK FLUID LVL SW SNS BRN WIRE CAN B BUS (+) CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN/RED WIRE DK GRN/WHT WIRE DK PNK WIRE DRIVER DOOR LATCH (IN DRIVER DOOR) DRIVER SEAT BELT SWITCH (LOWER LEFT "B" PILLAR) DRV SEAT BELT SW SNS ELECTRONICS EXCEPT BASE BASE FUSE 14 FUSE 17 FUSED B(+) (I.O.D) GRN WIRE GROUND HEADLAMP SWITCH HOT AT ALL TIMES IGNITION SWITCH IGNITION SWITCH SENSE LEFT REAR DOOR LATCH (REAR OF LEFT REAR DOOR) LIFTGATE AJAR SW SNS LIFTGATE DOOR LATCH (INSIDE LIFTGATE) LIN BUS LT BLU WIRE LT DR AJAR SW SNS LT GRN WIRE LT GRN/GRY WIRE ORG/ WIRE PARK BRAKE SW SNS PARKING BRAKE SWITCH (REAR OF FRONT CENTER CONSOLE) PASSENGER DOOR LATCH (PASSENGER DOOR) AJAR SW SNS RED WIRE RED/DK BLU WIRE RED/LT GRN WIRE RF DOOR AJAR SW SNS RIGHT REAR DOOR LATCH (RIGHT REAR DOOR) RR DOOR AJAR SW SNS SEAT BELT WARN SENTRY KEY REMOTE ENTRY/ WCM MODULE (RIGHT OF STEERING COLUMN) STEERING CONTROL MODULE (AT STEERING COLUMN) TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT) VIO WIRE VIO/BRN WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE W/ HEATED MIRRORS WHT WIRE WHT/DK GRN WIRE WHT/ORG WIRE WHT/PNK WIRE YEL WIRE
