Jeep Compass I (2006-2010) 12 2 19 10 20 dnshift sig Wiring diagram
This page shows the only wiring diagram for the component.12 2 19 10 20 dnshift sig, which is found in the car Jeep Compass I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 12 2 19 10 20 dnshift sig (1 of 1)
12 2 19 10 20 DNSHIFT SIG
AUTOSTICK DNSHIFT SIG
AUTOSTICK UPSHIFT SIG
B(+)
BLK WIRE
BLK/YEL WIRE
BRK SIG 2
BRK TRANS SOLENOID
BRK TRANS SOLENOID UNLOCK
BRN/YEL WIRE
C BUS (+)
CLUSTER
DK BLU WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/LT BLU WIRE
DK GRN/LT GRN WIRE
DK GRN/PNK WIRE
ELECTRONICS COMPUTER DATA LINES SYSTEM IGN SW OUT (RUN-START)
FUSE 14
FUSE 4
FUSED B (+)
GROUND
GRY WIRE
HOT AT ALL TIMES
IGN SW OUT
LT BLU/DK GRN WIRE
ORG/ WIRE
ORG/GRY WIRE
PANEL LAMPS DRV
PNK WIRE
PNK/GRY WIRE
RED WIRE
RED/DK BLU WIRE
RED/ORG WIRE
SHIFT LEVER ASSEMBLY
STOP LAMP SWITCH (LEFT SIDE OF BRAKE PEDAL)
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT)
UNLOCK
UPSHIFT SIG
WHT/BLK WIRE
WHT/LT BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/DK GRN WIRE
Go to component -> Shift interlock circuit, with autostick -> 12 2 19 10 20 DNSHIFT SIG
