Jeep Compass I (2006-2010) 1 2 3 5 low data link high data link sensor supply sensor ground Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 5 low data link high data link sensor supply sensor ground, which is found in the car Jeep Compass I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 5 low data link high data link sensor supply sensor ground (1 of 1)
1 2 3 5 LOW DATA LINK HIGH DATA LINK SENSOR SUPPLY SENSOR GROUND
ANTI-LOCK BRAKES MODULE (ENGINE COMPT NEAR RIGHT SHOCK TOWER)
B(+)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BUS -
COMPUTER DATA LINES SYSTEM
DYNAMICS SENSOR (W/ ESP) (CENTER BODY BELOW INSTRUMENT PANEL)
ELECTRONICS
FUSE 34
GROUND
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH OUTPUT (RUN-START)
PNK WIRE
PNK/GRY WIRE
RED WIRE
RED/BLK WIRE
STEERING ANGLE SENSOR (BASE OF RIGHT "B" PILLAR)
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE ENGINE COMPT)
VIO/DK BLU WIRE
VIO/LT BLU WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
WHT/LT BLU WIRE
WHT/YEL WIRE
Go to component -> Electronic power steering circuit -> 1 2 3 5 LOW DATA LINK HIGH DATA LINK SENSOR SUPPLY SENSOR GROUND
