Jeep Commander I (2005-2010) trailer tow right stop/ turn sig Wiring diagram
This page shows the only wiring diagram for the component.trailer tow right stop/ turn sig, which is found in the car Jeep Commander I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer tow right stop/ turn sig (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE 19
FUSE 21
FUSE 6
FUSE 9
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK
LEFT TAIL/ STOP/TURN LAMP
LEFT TURN TRAILER TOW RELAY
PARK LAMP RELAY
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWER OUTLET RELAY
RED WIRE
RIGHT TURN TRAILER TOW RELAY
TRAILER TOW 4-WAY WIRING (UNDER REAR OF VEHICLE)
TRAILER TOW 7-WAY WIRING (UNDER REAR OF VEHICLE)
TRAILER TOW LEFT STOP/ TURN SIG
TRAILER TOW RIGHT STOP/ TURN SIG
TRAILER TOW TERMINAL WIRING
WHT WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/LT GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> TRAILER TOW RIGHT STOP/ TURN SIG
