Jeep Commander I (2005-2010) second row mode door actuator Wiring diagrams
This page contains all the electrical diagrams for the component. second row mode door actuator, in which he is found in the car Jeep Commander I (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram second row mode door actuator (1 of 2)
1 2 3 FAN RLY OUT GROUND FAN RLY OUT
3 2 1 A/C PRESSURE SIG
4 5 AAT SIG SENS GND
5.7L
A/C CLUTCH RELAY
A/C CLUTCH RELAY CONTROL
A/C PRESSURE SIG
A/C PRESSURE TRANSDUCER (RIGHT FRONT OF ENGINE COMPT)
AMBIENT AIR TEMPERATURE SENSOR (FRONT CENTER OF ENGINE COMPT)
BLK WIRE
BLK/DK GRN WIRE
BLK/GRY WIRE
BLK/LT BLU WIRE
BRN WIRE
BRN/DK GRN WIRE
BRN/PNK WIRE
BRN/VIO WIRE
DK BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/LT BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
EVAPORATOR TEMPERATURE SENSOR (LEFT SIDE OF HVAC UNIT)
EXCEPT 3.7L
EXCEPT 5.7L
FCM SENS RETURN
FRONT CONTROL MODULE
FRONT MODE DOOR ACTUATOR (LEFT SIDE OF HVAC UNIT)
FUSE 12
FUSE 21
FUSE 23
FUSE 27
FUSE IG SW OUT (RUN-START) ECT SIGNAL SENSOR GROUND 12 20 27
FUSED B (+)
GEN FIELD CTRL
GROUND
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 18
HOT IN RUN OR START JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 24
HYDRAULIC COOLING FAN MODULE (5.7L) (FRONT OF ENGINE COMPT)
IN HEADLAMP, DASH HARNESS)
IPM FUSED B(+)
JUNCTION BLOCK (LEFT SIDE OF DASH)
LT BLU WIRE
LT BLU/BRN WIRE
LT BLU/GRY WIRE
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/YEL WIRE
ORG/ WIRE
PNK WIRE
PNK/GRY WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PREMIUM
RADIATOR FAN HIGH RELAY (3.7L/4.7L)
RADIATOR FAN LOW RELAY (3.7L/4.7L)
RADIATOR FAN SOLENOID CTRL
RADIATOR FAN/MOTOR ASSEMBLY (3.7L/4.7L) (FRONT OF ENGINE COMPT)
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RIGHT BLEND DOOR ACTUATOR (CENTER OF HVAC UNIT)
SECOND ROW MODE DOOR ACTUATOR
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> SECOND ROW MODE DOOR ACTUATOR
Wiring diagram second row mode door actuator (2 of 2)
5.7L
A/C CLUTCH RELAY
A/C CLUTCH RELAY CONTROL
BLK/DK GRN WIRE
BLK/GRY WIRE
BRN WIRE
BRN/DK GRN WIRE
BRN/PNK WIRE
BRN/VIO WIRE
DK BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/LT BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
EVAPORATOR TEMPERATURE SENSOR (LEFT SIDE OF HVAC UNIT)
EXCEPT 3.7L
EXCEPT 5.7L
FRONT CONTROL MODULE
FRONT MODE DOOR ACTUATOR (LEFT SIDE OF HVAC UNIT)
FUSE 12
FUSE 21
FUSE 23
FUSE IG SW OUT (RUN-START) ECT SIGNAL SENSOR GROUND 12 20 27
FUSED B (+)
GEN FIELD CTRL
GROUND
GRY WIRE
HIGH SPEED FAN RLY OUT
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 18
HOT IN RUN OR START JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 24
HYDRAULIC COOLING FAN MODULE (5.7L) (FRONT OF ENGINE COMPT)
IN HEADLAMP, DASH HARNESS)
IPM FUSED B(+)
LEFT BLEND DOOR ACTUATOR (LEFT SIDE OF HVAC UNIT)
LOW SPEED FAN RLY OUT
LT BLU WIRE
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/YEL WIRE
ORG/ WIRE
PNK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
RADIATOR FAN HIGH RELAY (3.7L/4.7L)
RADIATOR FAN LOW RELAY (3.7L/4.7L)
RADIATOR FAN SOLENOID CTRL
RADIATOR FAN/MOTOR ASSEMBLY (3.7L/4.7L) (FRONT OF ENGINE COMPT)
RECIRCULATION DOOR ACTUATOR (RIGHT SIDE OF HVAC UNIT)
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
SECOND ROW MODE DOOR ACTUATOR
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> SECOND ROW MODE DOOR ACTUATOR
