Jeep Commander I (2005-2010) rear mode door actuator Wiring diagram
This page shows the only wiring diagram for the component.rear mode door actuator, which is found in the car Jeep Commander I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear mode door actuator (1 of 1)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER 1
COMPASS INSIDE MODULE REARVIEW MIRROR
CONSOLE POWER OUTLET
DATA LINK CONNECTOR
DK BLU WIRE
DOOR PASSENGER LOCK DOOR RELAY UNLOCK RELAY FUSE 18
EXCEPT BASE
EXCEPT DAY/NIGHT DAY/NIGHT MIRROR MIRROR
EXCEPT PREMIUM PREMIUM
FROM FUSE 30 (IPM) (DIAGRAM 1 OF 4)
FROM RUN RELAY (DIAGRAM 3 OF 4)
FRONT BLOWER MOTOR RELAY POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
FUSE 10
FUSE 13 FUSE 14
FUSE 15
FUSE 4
FUSE 5
FUSE 9
GRY WIRE
HANDS FREE EXCEPT HANDS FREE PNK/ 13 1 WIRE
INSTRUMENT PANEL POWER OUTLET
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
LEFT REAR HEATED SEAT SWITCH
LOWER BANK SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK ASSIST
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/YEL WIRE
POWER OUTLET RELAY
RADIO AMPLIFIER (W/ PREMIUM AUDIO)
REAR A/C HEATER CONTROL
REAR BLEND DOOR ACTUATOR
REAR DRIVER WIPER DOOR RELAY UNLOCK RELAY FUSE 1
REAR MODE DOOR ACTUATOR
REAR POWER OUTLET
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/ORG WIRE
RED/VIO WIRE
RELAY
RIGHT CLUSTER REAR TIRE PRESSURE TRANS- PONDER (IF EQUIPPED)
RIGHT REAR A/C HEATED HEATER SEAT SWITCH CONTROL
RUN WIRE
RUN/ ACCESSORY RELAY
STEERING CLUSTER UPPER BANK CONTROL SWITCH MODULE
TAN WIRE
TO FUSE 1 (DIAGRAM 3 OF 4)
TO FUSE 19 (PDC) (DIAGRAM 4 OF 4)
TO FUSE 22 (DIAGRAM 4 OF 4)
TO FUSE 4 (PDC) (DIAGRAM 4 OF 4)
TRAILER TOW 7 WAY WIRING
WIPER WIPER HIGH/LOW ON/OFF RELAY RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> REAR MODE DOOR ACTUATOR
