Jeep Commander I (2005-2010) pnk lt Wiring diagram
This page shows the only wiring diagram for the component.pnk lt, which is found in the car Jeep Commander I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk lt (1 of 1)
ANGLE SENSOR
BLK WIRE
BLK/DK GRN WIRE
CAN C BUS (+)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DYNAMICS SENSOR (W/ ESP: BEHIND RIGHT FRONT SEAT)
FUSE 28
FUSED B (+)
FUSED IGN
GRN WIRE
GROUND
HIGH DATA
HOT AT ALL TIMES
HOT W/ REMOTE START RELAY ENERGIZED JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 20
LOW DATA
PNK LT WIRE
PNK/LT GRN WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RED/DK GRN WIRE
SENS GND
SENS SUPPLY
VIO/DK BLU WIRE
VIO/LT BLU WIRE
WHT/DK BLU WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/YEL WIRE
Go to component -> Electronic power steering circuit -> PNK LT WIRE
