Jeep Commander I (2005-2010) low speed fan rly out Wiring diagrams
This page contains all the electrical diagrams for the component. low speed fan rly out, in which he is found in the car Jeep Commander I (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram low speed fan rly out (1 of 2)
29 35 34 FUSED B(+) CAN C BUS (-) CAN C BUS (+)
BLK/DK GRN WIRE
BRN WIRE
BRN/VIO WIRE
CAN C CAN C CTRL BUS(+) BUS(-) IPM
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
ECT SIGNAL
ENGINE COOLANT TEMPERATURE SENSOR (3.7L/4.7L: TOP FRONT OF ENGINE)
FUSE 23
FUSE 29
FUSED B (+)
GROUND
GRY WIRE
HIGH SPEED FAN RLY OUT
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 21
HYDRAULIC COOLING FAN MODULE (5.7L) (FRONT OF ENGINE COMPT)
IPM FRONT CONTROL MODULE RLY CTRL
LOW SPEED FAN RLY OUT
LT BLU WIRE
LT GRN WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
RADIATOR FAN HIGH RELAY (3.7L/ 4.7L)
RADIATOR FAN LOW RELAY (3.7L/ 4.7L)
RADIATOR FAN SOLENOID CTRL
RADIATOR FAN/MOTOR ASSEMBLY (3.7L/4.7L)
RED WIRE
RED/GRY WIRE
RLY
RLY CTRL
SENSOR GROUND
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
Go to component -> Cooling fan circuit -> LOW SPEED FAN RLY OUT
Wiring diagram low speed fan rly out (2 of 2)
5.7L
A/C CLUTCH RELAY
A/C CLUTCH RELAY CONTROL
BLK/DK GRN WIRE
BLK/GRY WIRE
BRN WIRE
BRN/DK GRN WIRE
BRN/PNK WIRE
BRN/VIO WIRE
DK BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/LT BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
EVAPORATOR TEMPERATURE SENSOR (LEFT SIDE OF HVAC UNIT)
EXCEPT 3.7L
EXCEPT 5.7L
FRONT CONTROL MODULE
FRONT MODE DOOR ACTUATOR (LEFT SIDE OF HVAC UNIT)
FUSE 12
FUSE 21
FUSE 23
FUSE IG SW OUT (RUN-START) ECT SIGNAL SENSOR GROUND 12 20 27
FUSED B (+)
GEN FIELD CTRL
GROUND
GRY WIRE
HIGH SPEED FAN RLY OUT
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 18
HOT IN RUN OR START JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 24
HYDRAULIC COOLING FAN MODULE (5.7L) (FRONT OF ENGINE COMPT)
IN HEADLAMP, DASH HARNESS)
IPM FUSED B(+)
LEFT BLEND DOOR ACTUATOR (LEFT SIDE OF HVAC UNIT)
LOW SPEED FAN RLY OUT
LT BLU WIRE
LT BLU/ORG WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/YEL WIRE
ORG/ WIRE
PNK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
RADIATOR FAN HIGH RELAY (3.7L/4.7L)
RADIATOR FAN LOW RELAY (3.7L/4.7L)
RADIATOR FAN SOLENOID CTRL
RADIATOR FAN/MOTOR ASSEMBLY (3.7L/4.7L) (FRONT OF ENGINE COMPT)
RECIRCULATION DOOR ACTUATOR (RIGHT SIDE OF HVAC UNIT)
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
SECOND ROW MODE DOOR ACTUATOR
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> LOW SPEED FAN RLY OUT
