Jeep Commander I (2005-2010) left audio aux Wiring diagram
This page shows the only wiring diagram for the component.left audio aux, which is found in the car Jeep Commander I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left audio aux (1 of 1)
AUDIO OUT GND
AUX AUDIO RTN/COM
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
CAN B BUS (+)
COMPUTER DATA LINES SYSTEM
DK GRN/BLK WIRE
DK GRN/WHT WIRE
DVD MONITOR
FUSE 27 (LEFT SIDE OF ENGINE COMPT)
FUSED B (+)
GROUND
GRY WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/TAN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
I/P AUDIO LEFT
I/R AUDIO RETURN
I/R AUDIO RIGHT
INTEGRATED POWER MODULE
JUNCTION BLOCK (LEFT SIDE OF DASH)
LEFT AUDIO AUX
LT BLU WIRE
MONITOR/DVD MEDIA SYSTEM
RED WIRE
REMOTE CTRL FUN 1
REMOTE CTRL FUN 2
REMOTE CTRL FUNCTION 1
REMOTE CTRL FUNCTION 2
RIGHT AUDIO AUX
SHIELD
VIDEO PLAY SIG
VIDEO RTN
VIDEO SIG
VIO/ORG WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/ORG WIRE
Go to component -> Dvd player circuit -> LEFT AUDIO AUX
