Jeep Commander I (2005-2010) lamp, dash harness) Wiring diagram
This page shows the only wiring diagram for the component.lamp, dash harness), which is found in the car Jeep Commander I (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamp, dash harness) (1 of 1)
AUTO HEADLAMP SENSOR
AUTO HEADLAMPS SIG
AUTO HEADLAMPS SIG RTN
BLK WIRE
BLK/LT BLU WIRE
CAN B BUS (+)
CLUSTER
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FRONT CONTROL MODULE
FRONT FOG LAMP RELAY
FRONT FOG LAMP RELAY CONTROL
FUSE 15
FUSE 37
FUSED B (+)
FUSED IGN SW OUT (RUN-START)
GROUND IPM
GRY WIRE
HIGH BEAM LAMP
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
IGN SW, RUN/ START
IN HEADLAMP, DASH HARNESS)
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
IPM
LAMP, DASH HARNESS)
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HIGH BEAM DRIVER
LEFT LOW BEAM DRIVER
LOW BEAM LAMP
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK BRK SW SNS
PARKING BRAKE SWITCH (BELOW CENTER CONSOLE)
PNK WIRE
PNK/WHT WIRE
RED WIRE
RIGHT HEADLAMP
RIGHT HIGH BEAM DRIVER
RIGHT LOW BEAM DRIVER
TAN WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/VIO WIRE
WIRELESS IGNITION NODE
Go to component -> Headlights circuit -> LAMP, DASH HARNESS)
