Jeep Commander I (2005-2010) instrument panel power outlet Wiring diagrams
This page contains all the electrical diagrams for the component. instrument panel power outlet, in which he is found in the car Jeep Commander I (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram instrument panel power outlet (1 of 2)
A/C HEATER CONTROL
ADJUSTABLE PEDALS SWITCH
AUTOMATIC A/C
BLK WIRE
CLUSTER
CONSOLE POWER OUTLET
DRIVER DOOR LATCH
DRIVER DOOR MODULE
DRIVER PASSENGER SEAT BELT SEAT BELT SWITCH SWITCH
DRIVER WINDOW/ DOOR LOCK SWITCH
EXCEPT EXCEPT PREMIUM PREMIUM W/O MEMORY W/ MEMORY SEATS SEATS
EXCEPT PREMIUM
FRONT BLOWER POWER MODULE
HANDS FREE MODULE
HEATED SEATS MODULE
INSTRUMENT PANEL POWER OUTLET
INVERTER MODULE
LEFT CUSHION PAD HEATER
LEFT REAR DOOR LATCH
LEFT SEAT BACK HEATER
LOWER BANK SWITCH
LT BLU WIRE
LT GRN WIRE
MANUAL A/C
ORG/ WIRE
PASSENGER DOOR LATCH
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER SEAT SWITCH
PREMIUM
RADIO
REAR POWER OUTLET
RIGHT REAR DOOR LATCH
RIGHT RIGHT CUSHION SEAT PAD BACK HEATER HEATER
SHIFT LEVER ASSEMBLY
STEERING ANGLE SENSOR
STEERING CONTROL MODULE
UPPER BANK SWITCH
W/ HEATED SEATS
W/ MEMORY
W/O MEMORY
WHT WIRE
WIRELESS IGNITION NODE
Go to component -> Ground distribution circuit (2 of 3) -> INSTRUMENT PANEL POWER OUTLET
Wiring diagram instrument panel power outlet (2 of 2)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER 1
COMPASS INSIDE MODULE REARVIEW MIRROR
CONSOLE POWER OUTLET
DATA LINK CONNECTOR
DK BLU WIRE
DOOR PASSENGER LOCK DOOR RELAY UNLOCK RELAY FUSE 18
EXCEPT BASE
EXCEPT DAY/NIGHT DAY/NIGHT MIRROR MIRROR
EXCEPT PREMIUM PREMIUM
FROM FUSE 30 (IPM) (DIAGRAM 1 OF 4)
FROM RUN RELAY (DIAGRAM 3 OF 4)
FRONT BLOWER MOTOR RELAY POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
FUSE 10
FUSE 13 FUSE 14
FUSE 15
FUSE 4
FUSE 5
FUSE 9
GRY WIRE
HANDS FREE EXCEPT HANDS FREE PNK/ 13 1 WIRE
INSTRUMENT PANEL POWER OUTLET
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
LEFT REAR HEATED SEAT SWITCH
LOWER BANK SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK ASSIST
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/YEL WIRE
POWER OUTLET RELAY
RADIO AMPLIFIER (W/ PREMIUM AUDIO)
REAR A/C HEATER CONTROL
REAR BLEND DOOR ACTUATOR
REAR DRIVER WIPER DOOR RELAY UNLOCK RELAY FUSE 1
REAR MODE DOOR ACTUATOR
REAR POWER OUTLET
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/ORG WIRE
RED/VIO WIRE
RELAY
RIGHT CLUSTER REAR TIRE PRESSURE TRANS- PONDER (IF EQUIPPED)
RIGHT REAR A/C HEATED HEATER SEAT SWITCH CONTROL
RUN WIRE
RUN/ ACCESSORY RELAY
STEERING CLUSTER UPPER BANK CONTROL SWITCH MODULE
TAN WIRE
TO FUSE 1 (DIAGRAM 3 OF 4)
TO FUSE 19 (PDC) (DIAGRAM 4 OF 4)
TO FUSE 22 (DIAGRAM 4 OF 4)
TO FUSE 4 (PDC) (DIAGRAM 4 OF 4)
TRAILER TOW 7 WAY WIRING
WIPER WIPER HIGH/LOW ON/OFF RELAY RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> INSTRUMENT PANEL POWER OUTLET
