Jeep Commander I (2005-2010) hazrd sw sens Wiring diagram

10 9 1 CAN B BUS(-) CAN B BUS(+) LIN BUS 3 2 CAN B (-) CAN B (+) 43 IPM 10 LR TURN SIG CTRL 48 IPM PARK LAMP RLY CTRL BASE BLK WIRE BLU WIRE BRAKE LAMP SW OUT BRN WIRE CENTER HIGH MOUNTED STOP LAMP CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE EXCEPT BASE FLIP-UP GLASS SW SNS FRONT CONTROL MODULE FUSE 10 FUSE 26 FUSE 8 FUSED PARK LAMP RELAY OUTPUT FUSED PARK LAMP RLY OUT GRN WIRE GROUND GRY WIRE HAZARD SWITCH HAZRD SW SENS HAZRD SW SENSE HOT AT ALL TIMES IN HEADLAMP, DASH HARNESS) INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) JUNCTION BLOCK (LEFT SIDE OF DASH) L TURN SIG LEFT HEADLAMP LEFT TAIL/ STOP/TURN LAMP LICENSE LAMP (BASE) LICENSE PLATE LAMP/REAR CAMERA ASSEMBLY LIGHT SWITCH LIN BUS LOWER BANK SWITCH LT BLU WIRE LT GRN WIRE MARKER LAMP ORG/ WIRE ORG/VIO WIRE PARK LAMP RELAY PARK/ TURN LAMP PARK/ TURN LAMP MARKER LAMP POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) R TURN SIG RED WIRE RIGHT HEADLAMP RIGHT TAIL/ STOP/TURN LAMP RR TURN SIG CTRL STOP LAMP SWITCH (LOWER LEFT SIDE OF DASH) TAIL/ STOP LAMP TAIL/ STOP LAMP TURN SIGNAL LAMP TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL LAMP VIO WIRE WHT WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/TAN WIRE WHT/VIO WIRE
