Jeep Commander I (2005-2010) 5 volt supply Wiring diagram

3 2 4 S/C SW SIG 1 S/C SW RTN S/C SW SIG 2 3.7L 3.7L/5.7L 4.7L 33 34 32 SPEED SENS SIG SENS GND SPEED SENS SIG 5 22 4 S/C SW RTN S/C SW SENSE 1 S/C SW SENSE 2 5 VOLT SUPPLY 8 5 FUSED B (+) GROUND ACCELERATOR PEDAL POSITION SENSOR (BASE OF ACCELERATOR PEDAL) APPS 1 APPS 1 SIG APPS 2 SENS GND APPS 2 SIG BLK WIRE BRAKE SW 1 SIG BRAKE SW 2 SIG BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/ORG WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE DK BLU/GRY WIRE DK BLU/LT GRN WIRE DK GRN/BRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM ETC MOTOR, +/- FUSE 16 FUSE 24 HOT AT ALL TIMES HOT IN RUN OR START INPUT SPEED SENSOR (EXCEPT 3.7L) (LEFT SIDE OF TRANSMISSION) JUNCTION BLOCK (LEFT SIDE OF DASH) LEFT SPEED CONTROL SWITCH LT BLU/DK GRN WIRE LT GRN/RED WIRE ORG/VIO WIRE OUTPUT SPEED SENSOR (EXCEPT 3.7L) (LEFT SIDE OF TRANSMISSION) PNK/LT GRN WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) RIGHT SPEED CONTROL SWITCH S/C SW RTN S/C SW SIG 1 S/C SW SIG 2 SENS GND STEERING CONTROL MODULE (IN STEERING WHEEL) STOP LAMP SWITCH (LOWER LEFT SIDE OF DASH) THROTTLE BODY (TOP FRONT OF ENGINE) TP 1 SIG TP 2 SIG TP SENSOR RTN VIO/BRN WIRE VIO/ORG WIRE WHT/BRN WIRE YEL/PNK WIRE
