Jeep Commander I (2005-2010) 4 3 2 1 blower mtr rly out front blower ctrl ground Wiring diagram

1 4 2 SUN SENS 1 SIG SUN SENS 2 SIG SUN SENS RTN 2 1 BLOWER MTR GND BLOWER MTR POWER 4 3 2 1 BLOWER MTR RLY OUT FRONT BLOWER CTRL GROUND A/C HEATER CONTROL BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/PNK WIRE CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/BRN WIRE DK BLU/LT BLU WIRE DK BLU/ORG WIRE DK BLU/VIO WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT BLOWER MOTOR FRONT BLOWER MOTOR RELAY FRONT BLOWER POWER MODULE (RIGHT SIDE OF HVAC UNIT) FUSE 1 FUSE 10 FUSE 14 GROUND FUSED RUN RLY OUT GRY/RED WIRE HOT AT ALL TIMES HOT W/ RUN RELAY ENERGIZED JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 5 LT BLU WIRE LT BLU/BRN WIRE LT BLU/GRY WIRE LT BLU/LT GRN WIRE LT BLU/PNK WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE ORG/BRN WIRE PNK WIRE PNK/ DK WIRE PNK/YEL WIRE REAR A/C HEATER CONTROL REAR BLEND DOOR ACTUATOR (ON REAR HVAC UNIT) REAR BLEND DOOR CTRL REAR BLOWER MOTOR (IN REAR HVAC UNIT) REAR BLOWER MOTOR RELAY REAR BLOWER MOTOR RESISTOR (ON REAR HVAC UNIT) REAR HVAC CTRL REAR MODE DOOR ACTUATOR (CENTER OF HVAC UNIT) REAR MODE DOOR CTRL REAR WINDOW DEFOGGER RELAY RED WIRE RED/BLK WIRE RED/LT GRN WIRE SUN SENS RETURN SUN SENSOR UPPER BANK SWITCH VIO WIRE VIO/DK BLU WIRE VIO/LT BLU WIRE VIO/ORG WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/ORG WIRE YEL WIRE
