Jeep Commander I (2005-2010) 1 2 3 4 5 6 drv seat recliner pos sens gnd drv seat recliner up drv Wiring diagram

1 2 3 4 5 6 DRV SEAT RECLINER POS SENS GND DRV SEAT RECLINER UP DRV ADJUSTABLE PEDAL MOTOR (AT PEDAL ASSEMBLY) ADJUSTABLE PEDAL SWITCH ADJUSTABLE PEDALS SENS RTN ADJUSTABLE PEDALS SENS SIG ADJUSTABLE PEDALS SW FWD ADJUSTABLE PEDALS SW RWD ADJUSTABLE PEDALS SW GND BACKWARD BLK WIRE CAN B BUS (+) CAN B BUS (+) FUSED B(+) ADJUSTABLE PEDALS SENS SPLY GROUND CIRCUIT BREAKER 2 COMPUTER DATA LINES SYSTEM DRIVER FRONT VERTICAL SEAT ADJUSTER MOTOR DRIVER HORIZONTAL SEAT ADJUSTER MOTOR (BELOW DRIVER SEAT) DRIVER REAR VERTICAL SEAT ADJUSTER MOTOR DRIVER RECLINER SEAT ADJUSTER MOTOR DRIVER SEAT SWITCH DRV SEAT HORIZ FWD DRV DRV SEAT HORIZ RWD DRV DRV SEAT REAR VERT DOWN DRV DRV SEAT RECLINER DOWN DRV DRV SEAT RECLINER POS SNS DRV SEAT SW SPLY FORWARD/ FRONT DOWN FRONT UP HOT AT ALL TIMES JUNCTION BLOCK (LEFT SIDE OF DASH) LT BLU/VIO WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK BLU WIRE LT GRN/DK GRN WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/ORG WIRE LT GRN/TAN WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE MEMORY SEAT MODULE (BELOW DRIVER SEAT) ORG/BRN WIRE ORG/DK BLU WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/VIO WIRE PREMIUM EXCEPT PREMIUM REAR DOWN REAR UP RECLINER DOWN RECLINER UP RED WIRE RED/YEL WIRE VIO/BRN WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/LT GRN WIRE VIO/ORG WIRE VIO/TAN WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/ORG WIRE YEL WIRE YEL/VIO WIRE
