Jeep Cherokee V facelift (2018-2024) sunrf sw sply Wiring diagrams
This page contains all the electrical diagrams for the component. sunrf sw sply, in which he is found in the car Jeep Cherokee V facelift (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunrf sw sply (1 of 2)
BLK WIRE
BLK/GRN WIRE
ELECTRONIC OVERHEAD MODULE
FSD B(+)
FSD IGN SW OUTPUT
FUSE 35
FUSE 66
HOT AT ALL TIMES
HOT W/ RUN/ACCESSORY 1 RELAY ENERGIZED
ORG/BLU WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/TAN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
SUNRF CLOSE SW SNS
SUNRF DIAGNOSTIC
SUNRF OPEN SW SNS
SUNRF SHADE PWR CLOSE(+)
SUNRF SHADE PWR OPEN(+)
SUNRF SW SPLY
SUNRF VENT SW SNS
SUNROOF MOTOR
SUNROOF SHADE MOTOR
VIO/RED WIRE
WHT WIRE
Go to component -> Double panel sunroof circuit -> SUNRF SW SPLY
Wiring diagram sunrf sw sply (2 of 2)
BLK WIRE
ELECTRONIC OVERHEAD MODULE
FSD B(+)
FSD IGN SW OUTPUT
FUSE 35
FUSE 66
HOT AT ALL TIMES
HOT W/ RUN/ACCESSORY 1 RELAY ENERGIZED
ORG/BLU WIRE
ORG/GRN WIRE
ORG/TAN WIRE
ORG/YEL WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
SUNRF CLOSE SW SNS
SUNRF OPEN SW SNS
SUNRF SW SPLY
SUNRF VENT SW SNS
SUNROOF MOTOR
VIO/RED WIRE
Go to component -> Single panel sunroof circuit -> SUNRF SW SPLY
