Jeep Cherokee V facelift (2018-2024) star can ihs ip connector Wiring diagram
This page shows the only wiring diagram for the component.star can ihs ip connector, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram star can ihs ip connector (1 of 1)
A/C HEATER CONTROL
A/C HEATER MODULE
BASE PREMIUM
BLK WIRE
BLU WIRE
CENTER CONSOLE LAMP
CHARGING USB PORT
CIGAR LIGHTER
CLUSTER
CONSOLE POWER OUTLET
CUP HOLDER LAMP
DATA LINK CONNECTOR
DYNAMICS SENSOR
ELECTRIC AIR HEATER
EMERGENCY ASSISTANCE MODULE
EXTERNAL DISC MODULE
FORWARD FACING CAMERA
FUEL DOOR SWITCH
GLOVE BOX LAMP)
HEADLAMP SWITCH
HUMIDITY SENSOR
IN-CAR TEMPERATURE SENSOR
INSIDE REAR VIEW MIRROR
INTEGRATED CENTER STACK SWITCH BANK MODULE
KEYLESS IGNITION NODE MODULE
LEFT FRONT FOOTWELL LAMP
LEFT LOWER COURTESY LAMP
LEFT REAR HEATED SEAT SWITCH
LEFT SEAT BACK VIDEO SCREEN MODULE
MEDIA PORT
RADIO
RAIN LIGHT SENSOR MODULE
RIGHT FRONT FOOTWELL LAMP
RIGHT LOWER COURTESY LAMP
RIGHT REAR HEATED SEAT SWITCH
RIGHT SEAT BACK VIDEO SCREEN MODULE
SCREEN CENTER STACK DISPLAY
SECURITY GATEWAY MODULE
SHIFT LEVER ASSEMBLY
STAR CAN C IP CONNECTOR
STAR CAN IHS IP CONNECTOR
STEERING COLUMN CONTROL MODULE
TRANSFER CASE SELECTOR SWITCH
VIDEO MODULE
W/ RAIN SENSOR
W/O RAIN SENSOR
Go to component -> Ground distribution circuit (2 of 4) -> STAR CAN IHS IP CONNECTOR
