Jeep Cherokee V facelift (2018-2024) shield camera shld Wiring diagram
This page shows the only wiring diagram for the component.shield camera shld, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shield camera shld (1 of 1)
BLK WIRE
BLU WIRE
CAMERA RTN
CAMERA SHLD
CAMERA SIG (-)
COMPUTER DATA LINES SYSTEM
DK GRN/BRN WIRE
DK GRN/ORG WIRE
FUSE 95
GRN WIRE
HOT W/ RUN 1 RELAY ENERGIZED
LIN BUS
NCA WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RADIO
REAR VIDEO CAMERA
RED WIRE
RUN RLY O/P
SHIELD
SHIELD CAMERA SHLD
WHT WIRE
Go to component -> Rear view camera circuit -> SHIELD CAMERA SHLD
