Jeep Cherokee V facelift (2018-2024) rh floor temp sens sig Wiring diagram

A/C HEATER MODULE AUTO HEADLAMP SIG BLK WIRE BLK/VIO WIRE BLOWER CONTROL BLOWER MOTOR RELAY BLU WIRE BLU/DK BLU WIRE BLU/GRY WIRE BLU/TAN WIRE CAN IHS (-) COMPUTER DATA LINES SYSTEM DEFOGGER RELAY CONTROL DEFOGGER SYSTEM DK BLU WIRE DK BLU/BLU WIRE DK BLU/GRN WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE DK GRN WIRE DOOR SIG DR DRV DRV COMN DRIVER DRV SIG EVAPORATOR TEMP SENSOR SIG FRONT MODE DOOR ACTUATOR FSD IGN RUN CTRL O/P FUSE 101 FUSE 13 FUSE 49 FUSED B (+) FUSED IGN RUN/START CTRL O/P GRN/DK BLU WIRE GROUND HOT AT ALL TIMES HOT W/ RUN 2 RELAY ENERGIZED HUMIDITY SENSOR LEFT BLEND LEFT BLEND DOOR ACTUATOR LEFT BLEND DOOR SIG LEFT BLEND DR COMMON DRIVER LEFT BLEND DR DRIVER LEFT FLOOR TEMP SENSOR SIGNAL LH BLEND DR LIN BUS CBC 2 MODE DOOR COMMON DRIVER MODE DOOR DRIVER MODE DOOR DRV MODE DOOR SIG MODE DR COMN ORG/BLU WIRE ORG/DK BLU WIRE ORG/GRY WIRE ORG/TAN WIRE ORG/VIO WIRE PANEL TEMPERATURE SENSOR SIG PNK/BLU WIRE PNK/GRN WIRE PNK/YEL WIRE POWER DISTRIBUTION CENTER ASSEMBLY RECIRCULATION RECIRCULATION DOOR ACTUATOR RECIRCULATION DOOR DRIVER RECIRCULATION DR RECIRCULATION DR COMMON DRV RED WIRE REF VOLT SPLY RH BLEND DOOR COMMON DRIVER RH FLOOR TEMP SENS SIG RH MODE DR 2 CONTR CLKWISE SIG RH PANEL TEMP SENS SIG RIGHT BLEND DOOR DRIVER RIGHT BLEND DOOR FEED RIGHT BLEND DOOR SIGNAL RIGHT MODE DOOR DRIVER RIGHT MODE DR 2 CLOCKWISE SIG RUN 1 RELAY SENSOR GROUND SIG GND TAN/DK BLU WIRE TAN/GRY WIRE TAN/ORG WIRE TAN/YEL WIRE WHT WIRE WHT/DK BLU WIRE WHT/VIO WIRE YEL/DK BLU WIRE
