Jeep Cherokee V facelift (2018-2024) rf height sens rtn Wiring diagram
This page shows the only wiring diagram for the component.rf height sens rtn, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf height sens rtn (1 of 1)
AIR COMPR FD
AIR SUSP
AIR SUSPENSION COMPRESSOR ASSEMBLY (RIGHT FRONT CORNER OF ENGINE COMPT)
AIR SUSPENSION CONTROL MODULE
AIR SUSPENSION RELAY
AIR SUSPENSION SOLENOID ASSEMBLY
AIR TANK ENABLE SOL
BLK WIRE
BRN/DK BLU WIRE
BRN/DK GRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN C (+)
COMPRESSOR)
COMPUTER DATA LINES SYSTEM
DK BLU/BLU WIRE
DK BLU/BRN WIRE
DK BLU/GRN WIRE
DK BLU/ORG WIRE
DK BLU/TAN WIRE
DK BLU/VIO WIRE
FUSE 5
GROUND
HOT AT ALL TIMES
LEFT FRONT HEIGHT SENSOR
LF AXLE VENT SOL
LF HEIGHT
LF HEIGHT SENS PWR
LF HEIGHT SENS RTN
LF HEIGHT SENS SIG
LR AXLE VENT SOL
ORG/BRN WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PRESS SENSOR SIG
REVERSE
RF AXLE VENT SOL
RF HEIGHT
RF HEIGHT SENS PWR
RF HEIGHT SENS RTN
RF HEIGHT SENS SIG
RIGHT FRONT HEIGHT SENSOR
RR AXLE VENT SOL
SENS PWR
SENS RTN
SENS SIG
SENSOR COMM RTN
SENSOR FEED
SP201 (3.6L FLEX)
TAN/BLU WIRE
TAN/BRN WIRE
TAN/DK BLU WIRE
TAN/DK GRN WIRE
TAN/GRY WIRE
TAN/WHT WIRE
TAN/YEL WIRE
TEMP
TEMP RTN
VALVE BODY FEED
VALVE CTRL
VALVE UNIT 1
VALVE UNIT 2
YEL WIRE
YEL/GRY WIRE
Go to component -> Electronic air suspension circuit (2 of 2) -> RF HEIGHT SENS RTN
