Jeep Cherokee V facelift (2018-2024) passenger power seat circuit breaker 3 Wiring diagrams
This page contains all the electrical diagrams for the component. passenger power seat circuit breaker 3, in which he is found in the car Jeep Cherokee V facelift (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger power seat circuit breaker 3 (1 of 3)
BLK WIRE
DK GRN/BLK WIRE
DRIVER FORWARD/ REARWARD SEAT LUMBAR MOTOR
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER POWER SEAT CIRCUIT BREAKER 2
DRIVER UP/DOWN SEAT LUMBAR MOTOR
DRV SEAT LMBR IN
DRV SEAT LMBR OUT
FSD B(+)
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LMBR DOWN DRV
LMBR DOWN PASS
LMBR UP DRV
LMBR UP PASS
PASS SEAT LMBR IN
PASS SEAT LMBR OUT
PASSENGER FORWARD/REARWARD SEAT LUMBAR MOTOR
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER POWER SEAT CIRCUIT BREAKER 3
PASSENGER UP/DOWN SEAT LUMBAR MOTOR
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
Go to component -> Lumbar circuit -> PASSENGER POWER SEAT CIRCUIT BREAKER 3
Wiring diagram passenger power seat circuit breaker 3 (2 of 3)
BLK WIRE
FRONT PASSENGER VARISTOR
FRONT PASSENGER VERTICAL SEAT ADJUSTER MOTOR
FSD B (+) PASS RCLNR UP SW SNS
GRN/BLU WIRE
GRN/DK GRN WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/TAN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
PASS FRT DN DRV
PASS FRT UP DRV
PASS HORIZ FWD DRV
PASS RCLNR DN SW SNS PASS HORIZ RWD DRV
PASS VERT RR DN DRV
PASS VERT RR UP DRV
PASSENGER HORIZONTAL SEAT ADJUSTER MOTOR
PASSENGER HORIZONTAL VARISTOR
PASSENGER POWER SEAT CIRCUIT BREAKER 3
PASSENGER RECLINER SEAT ADJUSTER MOTOR
PASSENGER SEAT SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY
REAR PASSENGER VARISTOR
REAR PASSENGER VERTICAL SEAT ADJUSTER MOTOR
RED WIRE
Go to component -> Passenger power seat circuit -> PASSENGER POWER SEAT CIRCUIT BREAKER 3
Wiring diagram passenger power seat circuit breaker 3 (3 of 3)
3.6L
6.2L
7-WAY TRAILER TOW WIRING
A/C HEATER MODULE
AIR SUSPENSION CONTROL MODULE
ANTI-LOCK BRAKES MODULE
AUTO SHUT DOWN RELAY
BLU WIRE
BLUNT CUT)
BODY CONTROL MODULE
CHARGE AIR COOLER COOLANT PUMP
CLUSTER
DATA LINK CONNECTOR
DIGITAL TV
DK GRN WIRE
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER POWER SEAT CIRCUIT BREAKER 2
DRIVER SEAT SWITCH
DRIVETRAIN CONTROL MODULE
ELECTRONIC LIMITED SLIP DIFFERENTIAL MODULE
EXCEPT 3.6L
EXCEPT 6.4L
FROM FUSE 35 (DIAGRAM 4 OF 6)
FUEL DOOR SWITCH
FUSE 10
FUSE 11
FUSE 12
FUSE 14
FUSE 15
FUSE 23
FUSE 26
FUSE 30
FUSE 32
FUSE 39
FUSE 44
FUSE 49
FUSE 50
FUSE 6
FUSE 60
FUSE 71
FUSE 82
FUSE 83
FUSE 84
FUSE 94
GRN WIRE
GRY WIRE
INTEGRATED CENTER STACK SWITCH BANK MODULE
MEMORY SEAT MODULE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER POWER SEAT CIRCUIT BREAKER 3
PASSENGER SEAT SWITCH
POWER LIFTGATE MODULE
RADIO, AMPLIFIER
RED WIRE
SHIFT LEVER ASSEMBLY
SP109 (3.6L)
SP110 (3.6L)
STEERING COLUMN CONTROL MODULE
TAN WIRE
TO RUN 1 RELAY (DIAGRAM 6 OF 6)
TRANSFER CASE SELECTOR SWITCH
TRANSMISSION CONTROL MODULE
VIO WIRE
W/ SATELLITE VIDEO
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> PASSENGER POWER SEAT CIRCUIT BREAKER 3
