Jeep Cherokee V facelift (2018-2024) pass mirror vertical drv Wiring diagram
This page shows the only wiring diagram for the component.pass mirror vertical drv, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass mirror vertical drv (1 of 1)
AUTO DAY/NIGHT MIRROR (-)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
FUSED B (+)
GRN WIRE
GRY WIRE
PASS BLIND SPOT IND DRV
PASS BLIND SPOT IND RTN
PASS MIRROR COMMON DRV
PASS MIRROR HORIZONTAL DRV
PASS MIRROR HTR DRV
PASS MIRROR HTR RTN
PASS MIRROR TURN SIG DRV
PASS MIRROR TURN SIG LAMP RTN
PASS MIRROR VERTICAL DRV
PASSENGER BLIND SPOT INDICATOR LAMP
PASSENGER BLIND SPOT INDICATOR LAMP/ AUTO DIM MIRROR
PASSENGER DOOR MODULE
PASSENGER MIRROR ADJUSTER MOTOR
PASSENGER MIRROR HEATER
PASSENGER TURN INDICATOR MIRROR LAMP
RED WIRE
VIO WIRE
W/ AUTO DIMMING
W/O AUTO DIMMING
WHT WIRE
WHT/BRN WIRE
Go to component -> Power mirrors circuit, base (2 of 2) -> PASS MIRROR VERTICAL DRV
