Jeep Cherokee V facelift (2018-2024) pass frt dn drv Wiring diagram
This page shows the only wiring diagram for the component.pass frt dn drv, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass frt dn drv (1 of 1)
BLK WIRE
FRONT PASSENGER VARISTOR
FRONT PASSENGER VERTICAL SEAT ADJUSTER MOTOR
FSD B (+) PASS RCLNR UP SW SNS
GRN/BLU WIRE
GRN/DK GRN WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/TAN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
PASS FRT DN DRV
PASS FRT UP DRV
PASS HORIZ FWD DRV
PASS RCLNR DN SW SNS PASS HORIZ RWD DRV
PASS VERT RR DN DRV
PASS VERT RR UP DRV
PASSENGER HORIZONTAL SEAT ADJUSTER MOTOR
PASSENGER HORIZONTAL VARISTOR
PASSENGER POWER SEAT CIRCUIT BREAKER 3
PASSENGER RECLINER SEAT ADJUSTER MOTOR
PASSENGER SEAT SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY
REAR PASSENGER VARISTOR
REAR PASSENGER VERTICAL SEAT ADJUSTER MOTOR
RED WIRE
Go to component -> Passenger power seat circuit -> PASS FRT DN DRV
