Jeep Cherokee V facelift (2018-2024) lmbr down drv Wiring diagram
This page shows the only wiring diagram for the component.lmbr down drv, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lmbr down drv (1 of 1)
BLK WIRE
DK GRN/BLK WIRE
DRIVER FORWARD/ REARWARD SEAT LUMBAR MOTOR
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER POWER SEAT CIRCUIT BREAKER 2
DRIVER UP/DOWN SEAT LUMBAR MOTOR
DRV SEAT LMBR IN
DRV SEAT LMBR OUT
FSD B(+)
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LMBR DOWN DRV
LMBR DOWN PASS
LMBR UP DRV
LMBR UP PASS
PASS SEAT LMBR IN
PASS SEAT LMBR OUT
PASSENGER FORWARD/REARWARD SEAT LUMBAR MOTOR
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER POWER SEAT CIRCUIT BREAKER 3
PASSENGER UP/DOWN SEAT LUMBAR MOTOR
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
Go to component -> Lumbar circuit -> LMBR DOWN DRV
