Jeep Cherokee V facelift (2018-2024) invert sw sig Wiring diagram
This page shows the only wiring diagram for the component.invert sw sig, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram invert sw sig (1 of 1)
110 VOLT LINE 1
110 VOLT LINE 2
110 VOLT LINE 3
AC POWER OUTLET
BLK WIRE
BODY CONTROL MODULE
CIGAR LIGHTER
CONSOLE POWER OUTLET
DIGITAL TV
DRIVER WINDOW/ DOOR LOCK SWITCH
FROM FUSE 45 (DIAGRAM 1 OF 6)
FROM RUN 1 RELAY (DIAGRAM 6 OF 6)
FROM RUN/ START RELAY (DIAGRAM 4 OF 6)
FROM STOP/START RELAY (DIAGRAM 3 OF 6)
FSD B(+)
FSD IGN SW
FUSE 104
FUSE 38
FUSE 66
FUSE 91
FUSE 93
FUSED B (+)
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/WHT WIRE
INSIDE REAR VIEW MIRROR
INVERT SW SIG
INVERTER MODULE (UNDER FRONT PASSENGER SEAT)
LPS DRIV
O/P
ORG/GRY WIRE
PANEL)
PNK/YEL WIRE
POSITION 1
POSITION 2
POWER DISTRIBUTION CENTER ASSEMBLY
POWER WINDOW CIRCUIT BREAKER 1
RAIN LIGHT SENSOR MODULE
REAR POWER OUTLET
RED WIRE
RED/GRN WIRE
RUN/ACCESSORY 1 RELAY
RUN/ACCESSORY 2 RELAY
STATUS IND DRV
SUNROOF MOTOR
SUNROOF SHADE MOTOR
TO CHARGING USB PORT (DIAGRAM 3 OF 6)
TO REAR WINDOW DEFOGGER RELAY (DIAGRAM 3 OF 6)
W/ VIDEO ENTERTAINMENT SYSTEM
Go to component -> Power distribution circuit (2 of 6) -> INVERT SW SIG
