Jeep Cherokee V facelift (2018-2024) decklid/ liftgate ajar switch sns Wiring diagram
This page shows the only wiring diagram for the component.decklid/ liftgate ajar switch sns, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram decklid/ liftgate ajar switch sns (1 of 1)
BLK WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
CAN C (+)
CAN IHS (-)
CLUSTER
COMPUTER DATA LINES SYSTEM
DECKLID/ LIFTGATE AJAR SWITCH SNS
DECKLID/ LIFTGATE B (+) REL SW
DRV DECKLID/ LIFTGATE REL
FUSE 14
FUSED
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LIFTGATE DOOR LATCH
POWER DISTRIBUTION CENTER ASSEMBLY
POWER LIFTGATE HANDLE SWITCH
RED WIRE
REL SW
RIGHT END OF DASH)
TAN/YEL WIRE
VIO WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Deck lid release circuit -> DECKLID/ LIFTGATE AJAR SWITCH SNS
