Jeep Cherokee V facelift (2018-2024) courtesy lamps driver Wiring diagram
This page shows the only wiring diagram for the component.courtesy lamps driver, which is found in the car Jeep Cherokee V facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram courtesy lamps driver (1 of 1)
BLK WIRE
BODY CONTROL MODULE
COURTESY LAMPS DRIVER
ELECTRONIC OVERHEAD MODULE
FSD B(+)
FUSE 23
GRY WIRE
HOT AT ALL TIMES
ORG/BLU WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/TAN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PANEL LAMPS DRV
POWER DISTRIBUTION CENTER ASSEMBLY
PWR CLOSE(+)
PWR OPEN(+)
READING LAMPS DRIVER
RED WIRE
RIGHT END OF DASH)
SNRF CLOSE SW SNS
SNRF OPEN SW SNS
SNRF SHADE
SNRF SHADE PWR CLOSE (+)
SNRF SHADE PWR OPEN (+) DECKLID/LGATE REL SW SENS GND
SNRF SW SUPPLY
SNRF VENT SW SNS
SUNROOF MOTOR
SUNROOF SHADE MOTOR
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UGDO ENABLE CTRL CIRCUIT
VIO/TAN WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Overhead console circuit -> COURTESY LAMPS DRIVER
