Jeep Cherokee IV (2007-2012) vio lt grn/ Wiring diagram
This page shows the only wiring diagram for the component.vio lt grn/, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vio lt grn/ (1 of 1)
BATT FD
BLK WIRE
CIRCUIT BREAKER 2
DN PASS
FWD PASS
GRY LT GRN WIRE
HOT AT ALL TIMES
HTD SYS/
JUNCTION BLOCK (LEFT SIDE OF DASH)
LT GRN/GRY WIRE
LT GRN/ORG WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
PASSENGER HORIZONTAL SEAT ADJUSTER MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER RECLINER SEAT ADJUSTER MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT SWITCH
PWR HORZ
PWR RCLNR
RED WIRE
RED/YEL WIRE
RWD PASS
STRNG WHL
UP PASS
VIO LT GRN/ WIRE
Go to component -> Passenger power seat circuit -> VIO LT GRN/ WIRE
