Jeep Cherokee IV (2007-2012) ud press sw sense od press sw sense Wiring diagram
This page shows the only wiring diagram for the component.ud press sw sense od press sw sense, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ud press sw sense od press sw sense (1 of 1)
12 27 IGN SW OUTPUT
AUTOSTICK UP
BLK WIRE
BRAKE SW SIG
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/LT BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FRONT CONTROL MODULE
FUSE IGNITION SWITCH OUTPUT (RUN/START)
INPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
L/R SOL CTRL VAR FRCE SOL FD SGNL GROUND GROUND GROUND
LINE PRESS SENS SIG OUTPUT SPEED SENS INPUT SPEED SENS SENS RTN TRANS TEMP SIG
MS SOL CTRL
ORG/BRN WIRE
OUTPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
PNK WIRE
PNK/WHT WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
SENSOR RTN
SHIFT LEVER ASSEMBLY (BASE OF SHIFT LEVER)
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
TRANS CTRL RELAY TRANS CTRL RLY OUT
TRANS CTRL RLY OUT
TRANS CTRL RLY OUT L/R PRESS SW SNS
TRS PARK SIG
UD PRESS SW SENSE OD PRESS SW SENSE
UD SOL CTRL
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WIRELESS IGNITION NODE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/TAN WIRE
YEL/WHT WIRE
Go to component -> 5.7l, a/t circuit (2 of 2) -> UD PRESS SW SENSE OD PRESS SW SENSE
