Jeep Cherokee IV (2007-2012) trailer tow terminal wiring Wiring diagram
This page shows the only wiring diagram for the component.trailer tow terminal wiring, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer tow terminal wiring (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE 19
FUSE 21
FUSE 6
FUSE 9
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK
LEFT TURN TRAILER TOW RELAY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK LAMP RELAY
PNK WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWER OUTLET RELAY
RED WIRE
RIGHT TURN TRAILER TOW RELAY
TRAILER TOW 4-WAY WIRING (UNDER REAR OF VEHICLE)
TRAILER TOW 7-WAY WIRING (UNDER REAR OF VEHICLE)
TRAILER TOW ASSEMBLY
TRAILER TOW TERMINAL WIRING
TRAILER TOW WIRING
TTOW ELEC BRK OUTPUT
VIO WIRE
WHT WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
WHT/YEL WIRE
YEL WIRE
