Jeep Cherokee IV (2007-2012) sunroof open sw sns Wiring diagram
This page shows the only wiring diagram for the component.sunroof open sw sns, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof open sw sns (1 of 1)
BLK WIRE
CAN B BUS (+)
CLOSE SW SNS
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSED B (+)
GROUND
HOT AT ALL TIMES
JUNCTION BLOCK (LEFT SIDE OF DASH)
OPEN SW SNS
ORG/LT BLU WIRE
ORG/LT GRN WIRE
ORG/TAN WIRE
ORG/YEL WIRE
RED WIRE
SUNROOF CLOSE SW SNS
SUNROOF OPEN SW SNS
SUNROOF SW SPLY
SUNROOF SWITCH
SUNROOF VENT SW SNS
VENT SW SNS
WHT WIRE
WHT/ORG WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF OPEN SW SNS
