Jeep Cherokee IV (2007-2012) rr glass ajar sw sns Wiring diagram

1 2 5 CAN BUS (-) CAN BUS (+) FT DRV DR AJAR SW IN 1 2 5 CAN BUS (-) CAN BUS (+) FT PASS DR AJAR SW IN BLK WIRE BRAKE FLUID LEVEL SENSOR (LEFT REAR OF ENGINE COMPT) BRK FLUID LEVEL SW SNS CAN-BUS CLUSTER COMPUTER DATA LINES SYSTEM DK GRN/ORG WIRE DK GRN/WHT WIRE DRIVER DOOR LATCH (DRIVER'S DOOR) DRIVER DOOR MODULE (DRIVER'S DOOR) DRIVER SEAT BELT TENSIONER (LEFT SIDE OF DRIVER'S SEAT) FLIP-UP GLASS LATCH FRONT CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) FT DRV DR AJAR SW IN FT PASS DR AJAR SW IN FUSE FUSED B(+) FUSED IGN SW OUT (RUN-START) GROUND HOT AT ALL TIMES HOT IN RUN OR START JUNCTION BLOCK (LEFT SIDE OF DASH) PNK/ WIRE LEFT LR DR REAR AJAT SW DOOR SIG LATCH (LEFT GROUND REAR DOOR) LIFTGATE AJAR SW SENS LIFTGATE AJAT SW SNSR LIFTGATE DOOR LATCH LIN BUS LR DOOR AJAR SW SENS LT GRN WIRE LT GRN/RED WIRE PARKING BRAKE SWITCH (UNDER CENTER CONSOLE) PASSENGER DOOR LATCH (FRONT PASSENGER'S DOOR) PASSENGER DOOR MODULE PNK WIRE PNK/LT GRN WIRE PRK BRK SW SENSE PRK BRK SW SNSR REAR WINDOW WIPER MOTOR (LOWER CENTER OF LIFTGATE) RED WIRE RIGHT RR DR REAR AJAT SW DOOR SIG LATCH (RIGHT GROUND REAR DOOR) RR DOOR AJAR SW SENS RR GLASS AJAR SW SENS RR GLASS AJAR SW SNS RR GLASS SW SNSR SEAT BELT SNSR SEAT BELT SW SENSE VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/LT GRN WIRE VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE
