Jeep Cherokee IV (2007-2012) passenger seat belt tensioner (right side of front Wiring diagram

1 2 SIGNAL GROUND 2 1 LINE 1 LINE 2 BLK/LT GRN WIRE BRN/LT GRN WIRE CAN C BUS (+) RUN/ST RLY OUT COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT TENSIONER (LEFT SIDE OF DRIVER'S SEAT) FUSE 29 FUSE 30 (LEFT SIDE OF ENGINE COMPT) PNK/ WIRE GROUND HOT IN ON OR START HOT W/ RUN RELAY ENERGIZED INTEGRATED POWER MODULE LEFT FRONT IMPACT SENSOR (LEFT FRONT OF ENGINE COMPT) LEFT SIDE IMPACT SENSOR 1 (LEFT "B" PILLAR) LH LINE 2 LH LINE 1 RH LINE 1 RH LINE 2 LH SENS 1 GND LT SENS 2 GND RT SENS 2 GND LT SENS 2 SIG RT SENS 2 SIG SENS 1 SIG LH SENS 1 SIG RH SENS 1 GND SENS VOLTAGE LINE 1- LINE 2- LT BLU WIRE LT BLU/BLK WIRE LT BLU/BRN WIRE LT BLU/DK GRN WIRE LT BLU/ORG WIRE LT BLU/TAN WIRE LT BLU/VIO WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK GRN WIRE LT GRN/ORG WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE OCCUPANT RESTRAINT CONTROLLER MODULE (UNDER CENTER CONSOLE) ORG/ WIRE ORG/LT BLU WIRE PASSENGER AIR BAG SQUIB (RIGHT SIDE OF DASH) PASSENGER SEAT BELT TENSIONER (RIGHT SIDE OF FRONT PASSENGER'S SEAT) PNK WIRE PNK/ORG WIRE PNK/VIO WIRE RIGHT FRONT IMPACT SENSOR (RIGHT FRONT OF ENGINE COMPT) SENS GND SENS SIG SENS GND SENS SIG GND SIGNAL TAN/LT GRN WIRE VIO WIRE VIO/LT BLU WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE YEL WIRE YEL/LT BLU WIRE
