Jeep Cherokee IV (2007-2012) memory driver pad seat cushion module heater Wiring diagram
This page shows the only wiring diagram for the component.memory driver pad seat cushion module heater, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory driver pad seat cushion module heater (1 of 1)
5.7L EXCEPT 5.7L 4WD
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP
DRIVER (W/O MEMORY) SEAT DRIVER LEFT BELT SEAT SEAT BACK SWITCH SWITCH HEATER
DRIVER DOOR LATCH
DRIVER WINDOW/ DOOR LOCK DRIVER DOOR SWITCH MODULE
DRIVER'S DOOR
ELECTRIC HEATED BACKLITE
ELECTRONIC OVERHEAD MODULE
EVAP SYSTEM MONITOR SWITCH TRAILER TOW 7-WAY WIRING
FLIP-UP GLASS LATCH
FUEL PUMP MODULE
INSIDE REARVIEW RAIN SENSOR MIRROR
LEFT REAR HEATED SEAT SWITCH
LEFT REAR SEAT BACK HEATER
LEFT TAIL/STOP TURN LAMP
LIFTGATE DOOR LATCH
LIGHTBAR LICENSE LAMP
LT BLU WIRE
MEMORY DRIVER PAD SEAT CUSHION MODULE HEATER
PARK ASSIST MODULE
REAR WIPER MOTOR
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR TIRE PRESSURE TRANSPONDER
RIGHT TAIL/STOP TURN LAMP
ROW SEAT BACK HEATER
SUNROOF MOTOR/ MODULE
TRAILER TOW 4-WAY WIRING
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> MEMORY DRIVER PAD SEAT CUSHION MODULE HEATER
