Jeep Cherokee IV (2007-2012) license light bar lamp Wiring diagram
This page shows the only wiring diagram for the component.license light bar lamp, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license light bar lamp (1 of 1)
1 3 B (+) IGN SW
35 34 CAN C BUS (-) CAN C BUS (+)
5.7L
B(+)
BACKUP LAMP FD
BACKUP LAMP FEED
BKUP LMP FD
BLK WIRE
BRN/LT BLU WIRE
CAN C BUS (+)
CAN-BUS
COM SNSR RTN
COMPUTER DATA LINES SYSTEM
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/YEL WIRE
FRONT CONTROL MODULE
FUSE 37
FUSED IGN SW OUT (RUN-START)
GROUND
HOT AT ALL TIMES
HOT AT ALL TIMES POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
INSIDE REARVIEW MIRROR
LEFT TAIL/ STOP/ TURN (BELOW LEFT LAMP REAR SEAT)
LICENSE LIGHT BAR LAMP
LT BLU WIRE
LT BLU/RED WIRE
LT GRN WIRE
PNK WIRE
PNK/WHT WIRE
RED WIRE
RIGHT TAIL/ STOP/ TURN LAMP
SHIFT LEVER ASSEMBLY (BASE OF SHIFT LEVER)
SNSR RTN
TRAILER TOW 7-WAY WIRING (UNDER REAR OF VEHICLE)
TRANS RNG
TRANSMISSION CONTROL MODULE (3.6L) (LEFT SIDE OF DASH)
TRANSMISSION SOLENOID/ PRESSURE SWITCH (5.7L)
TRANSMISSION SOLENOID/TRS ASSEMBLY
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WIRELESS IGNITION NODE
Go to component -> Backup lamps circuit -> LICENSE LIGHT BAR LAMP
