Jeep Cherokee IV (2007-2012) left front door speaker Wiring diagram
This page shows the only wiring diagram for the component.left front door speaker, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door speaker (1 of 1)
AMP LF DR SPKR (-) AMP RF DR SPKR (-) AMP LR DR SPKR (-)
AMP RR DR SPKR (-) AMP SUBWOOFER 1 (-)
BLK WIRE
BLK/LT GRN WIRE
CAN BUS(+) LR AUD (+) RR AUD (+) GND AMP LH I/P SPKR (-) AMP RH I/P SPKR (-)
CAN BUS(-) LR AUD (-) RR AUD (-) GND
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/LT GRN WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DK GRN/YEL WIRE
FUSED B (+)
GROUND
GRY WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LEFT REAR DOOR SPEAKER
LIN BUS
LT GRN GRY WIRE
LT GRN WIRE
LT GRN/RED WIRE
RADIO AMPLIFIER (LEFT REAR CARGO COMPARTMENT FLOOR)
RIGHT FRONT DOOR SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT STEERING WHEEL SWITCH
SNSE RTN REM RAD SW
STEERING CONTROL MODULE (AT STEERING WHEEL)
SW SIG REM RAD CTRL
WHT WIRE
WHT/ORG WIRE
YEL/RED WIRE
Go to component -> Radio circuit (2 of 2) -> LEFT FRONT DOOR SPEAKER
