Jeep Cherokee IV (2007-2012) dimm sig sel Wiring diagrams

ADJUSTABLE PEDAL MOTOR (AT PEDAL ASSEMBLY) ADJUSTABLE PEDALS MOTOR AFT ADJUSTABLE PEDALS MOTOR FORWARD ADJUSTABLE PEDALS RELAY ADJUSTABLE PEDALS RELAY BATT FD ADJUSTABLE PEDALS SWITCH BLK WIRE DIMM SIG SEL DK BLU WIRE FRONT CONTROL MODULE ADJUSTABLE PEDALS RELAY CONTROL FUSE 14 GROUND HOT AT ALL TIMES INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) LT GRN WIRE LT GRN/DK BLU WIRE LT GRN/TAN WIRE ORG/ WIRE ORG/BRN WIRE RED WIRE RED/ORG WIRE

BATT FD BLK WIRE BLK/WHT WIRE CAN B BUS (+) CIRCUIT BREAKER 2 CLUSTER COMPUTER DATA LINES SYSTEM DIMM SIG DIMM SIG SEL DRIVER CUSHION PAD HEATER FUSE 10 GROUND GRY/LT GRN WIRE HEATED SEAT MODULE (UNDER PASSENGER'S SEAT) HOT AT ALL TIMES HOT W/ RUN RELAY ENERGIZED IGN R IND DRV IND DRV SEAT LOW RR HEATED JUNCTION BLOCK (LEFT SIDE OF DASH) LEFT REAR HEATED SEAT SWITCH LEFT REAR SEAT BACK HEATER LEFT SEAT BACK HEATER LIN BUS LOWER SWITCH BANK LR HEATED SEAT HIGH IND DRV LR HEATED SEAT LOW IND DRV LR HEATED SEAT SW SENSE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK BLU WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/ORG WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE LT RR HEAT OUT ORG/BRN WIRE PASSENGER CUSHION PAD HEATER PNK/YEL WIRE RED WIRE RED/YEL WIRE RIGHT REAR CUSHION SEAT HEATER RIGHT REAR HEATED SEAT SWITCH RIGHT SEAT BACK HEATER RR HEATED SEAT HIGH IND DRV RR HEATED SEAT LOW IND DRV RR HEATED SEAT SW RR HEATED SEAT SW SNS RT RR HEAT OUT SEAT BACK HEATER SEAT HIGH LR HEATED SEAT HIGH RR HEATED SEAT LOW LR HEATED SEAT SW SNS LR HEATED SENSE WHT WIRE WHT/ORG WIRE
