Jeep Cherokee IV (2007-2012) adjustable pedals relay batt fd Wiring diagram
This page shows the only wiring diagram for the component.adjustable pedals relay batt fd, which is found in the car Jeep Cherokee IV (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adjustable pedals relay batt fd (1 of 1)
ADJUSTABLE PEDAL MOTOR (AT PEDAL ASSEMBLY)
ADJUSTABLE PEDALS MOTOR AFT
ADJUSTABLE PEDALS MOTOR FORWARD
ADJUSTABLE PEDALS RELAY
ADJUSTABLE PEDALS RELAY BATT FD
ADJUSTABLE PEDALS SWITCH
BLK WIRE
DIMM SIG SEL
DK BLU WIRE
FRONT CONTROL MODULE ADJUSTABLE PEDALS RELAY CONTROL
FUSE 14
GROUND
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
LT GRN WIRE
LT GRN/DK BLU WIRE
LT GRN/TAN WIRE
ORG/ WIRE
ORG/BRN WIRE
RED WIRE
RED/ORG WIRE
Go to component -> Adjustable pedal circuit -> ADJUSTABLE PEDALS RELAY BATT FD
