Jeep Cherokee III facelift (2004-2007) transfer case selector switch panel lamp drv Wiring diagram
This page shows the only wiring diagram for the component.transfer case selector switch panel lamp drv, which is found in the car Jeep Cherokee III facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer case selector switch panel lamp drv (1 of 1)
A/C HEATER CONTROL PANEL LAMP DRV
BLK WIRE
BRN WIRE
CLUSTER PANEL LAMP DRV
DK BLU WIRE
FUSE 10
FUSED PARK LAMP RLY OUT
GROUND
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
JUNCTION BLOCK (LEFT SIDE OF DASH)
LOWER BANK SWITCH
ORG/ WIRE
ORG/BRN WIRE
PANEL LAMPS DRV
PARK LAMP RELAY
SHIFT LEVER ASSEMBLY (BASE OF SHIFT LEVER)
TRANSFER CASE SELECTOR SWITCH PANEL LAMP DRV
UPPER BANK SWITCH
WHT WIRE
WHT/LT BLU WIRE
Go to component -> Instrument illumination circuit -> TRANSFER CASE SELECTOR SWITCH PANEL LAMP DRV
