Jeep Cherokee III facelift (2004-2007) shift pres- sure sol Wiring diagram
This page shows the only wiring diagram for the component.shift pres- sure sol, which is found in the car Jeep Cherokee III facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift pres- sure sol (1 of 1)
1 2 3 4 5 6 7 8 9 10 23 24 25 26 27 28 29 30 SCI TRANSMIT
1-2/ 4-5 SOL 3-4 SOL
2-3 SOL
BLK WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (UNDER DASH)
DK GRN/BLK WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
ELECTROHYDRAULIC CONTROL UNIT ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
FUSE 24
HOT IN RUN OR START
JUNCTION BLOCK (LEFT SIDE OF DASH)
MOD PRES SOL CTRL SHIFT PRES SOL CTRL SOL SPPLY VOLT CAN C BUS (+) CAN C BUS (-)
MODU- LATION PRES- SURE SOL CTRL TCC SOL
P/N SWITCH
PNK/DK GRN WIRE
PNK/LT GRN WIRE
SHIFT PRES- SURE SOL
TRANS RLY OUT GROUND
TRANS- MISSION TEMPERATURE SENSOR
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RELAY
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/ORG WIRE
YEL/TAN WIRE
Go to component -> 3.7l, a/t circuit -> SHIFT PRES- SURE SOL
