Radio circuits, base radio for Jeep Cherokee III (2001-2004)

ANTENNA BLK WIRE BODY CONTROL MODULE BRN/RED WIRE CLOCK- SPRING DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN) DK BLU/ORG WIRE DK BLU/PNK WIRE DK BLU/WHT WIRE DK GRN/ORG WIRE DK GRN/WHT WIRE FUSE 30 FUSE 5 HOT AT ALL TIMES HOT IN RUN OR ACC JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) L REAR (+) L REAR (-) R REAR (-) R REAR (+) GROUND LEFT DASH SPEAKER LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN/DK GRN WIRE LT GRN/RED WIRE MODE NCA WIRE ORG/ WIRE ORG/GRY WIRE ORG/RED WIRE PANEL LAMPS FEED PCI BUS PRESET R FRONT (-) R FRONT (+) L FRONT (-) L FRONT (+) GROUND FUSED B+ RADIO RADIO CONTROL MUX RADIO MUX RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE REMOTE RADIO SWITCH LEFT REMOTE RADIO SWITCH RIGHT RIGHT DASH SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER SEEK DOWN SEEK UP TAN/DK GRN WIRE VIO WIRE VOL DOWN VOL UP WHT WIRE WHT/DK GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/VIO/DK BLU WIRE YEL/VIO/WHT WIRE
