Jeep Cherokee III (2001-2004) speed control switch 2 wiring diagram
This page shows the only wiring diagram for the component.speed control switch 2, which is found in the car Jeep Cherokee III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
speed control switch 2 wiring diagram (1 of 1)
AT DRIVER'S SEAT)
BLK WIRE
BLK/LT BLU WIRE
BRAKE LAMP SWITCH (TOP OF BRAKE PEDAL)
BRAKE SW
BRN WIRE
CLOCK- SPRING
COAST
CRUISE INDICATOR
DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN)
DK BLU WIRE
DK BLU/RED WIRE
DUMP
ELECTRONIC SPEED CONTROL SERVO (BELOW THE BATTERY TRAY)
FUSE 22
FUSED IGN PCI BUS CRUISE CONTROL LAMP CONTROL
HOT IN RUN OR START
INSTRUMENT CLUSTER
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/DK GRN WIRE
PCI BUS
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF FIREWALL)
PWR SUPPLY
RED WIRE
RED/LT GRN WIRE
RESUME/ ACCEL
SENSOR GND
SET-
SHIFTER ASSEMBLY BRAKE SWITCH SIGNAL
SPEED CONTROL SWITCH 1
SPEED CONTROL SWITCH 2
SPEED SW SIG
TAN/RED WIRE
VACUUM
VACUUM SOL
VENT
VENT SOL
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/PNK WIRE
YEL WIRE
YEL/VIO/BRN WIRE
Go to component -> Cruise control circuit -> SPEED CONTROL SWITCH 2
