Jeep Cherokee III (2001-2004) right rear door power lock motor/ ajar switch Wiring diagram
This page shows the only wiring diagram for the component.right rear door power lock motor/ ajar switch, which is found in the car Jeep Cherokee III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door power lock motor/ ajar switch (1 of 1)
ADJUSTABLE PEDALS MODULE
AIR BAG CONTROL MODULE
BASE
BASE PREMIUM
BLK WIRE
BRAKE LAMP SWITCH
DRIVER CYLINDER LOCK SWITCH
DRIVER DOOR LOCK/MOTOR AJAR SWITCH
DRIVER DOOR MODULE
ELECTRIC BRAKE
OTHER
PASSENGER DOOR LOCK/MOTOR AJAR SWITCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SWITCH
PASSENGER POWER SEAT SWITCH
PASSENGER REAR POWER WINDOW SWITCH
PNK WIRE
POWER AMPLIFIER
RADIO
REAR POWER OUTLET
RIGHT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH
RIGHT REAR LAMP ASSEMBLY
Go to component -> Ground distribution circuit (3 of 4) -> RIGHT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH
