Jeep Cherokee III (2001-2004) pnk sci transmit Wiring diagram

10 8 PCI BUS FLASH ENABLE 15 17 PCI BUS FLASH ENABLE ADJUSTABLE PEDALS MODULE AIR BAG CONTROL MODULE (BELOW CENTER FLOOR CONSOLE, NEAR PARK BRAKE) AUTOMATIC ZONE CONTROL MODULE BLK/LT GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BODY CONTROL MODULE (ON LEFT END OF DASH, ATTACHED TO JUNCTION BLOCK) COMPACT DISC CHANGER (PREMIUM) DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN) DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN) DRIVER DOOR MODULE (BEHIND LEFT FRONT DOOR PANEL) FUSE 17 HOT AT ALL TIMES INSTRUMENT CLUSTER JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LT GRN WIRE LT GRN/DK GRN WIRE PASSENGER DOOR MODULE (BEHIND RIGHT FRONT DOOR PANEL) PCI BUS PNK SCI TRANSMIT WIRE PNK WIRE PNK/RED WIRE POWER AMPLIFIER (PREMIUM) (UNDER PASSENGER SIDE REAR SEAT CUSHION) POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL) RADIO RAIN SENSOR (W/ AUTOWIPE) SCI RECEIVE SEAT MODULE (W/ MEMORY SEATS) (UNDER FRONT OF DRIVER'S SEAT) SENTRY KEY IMMOBILIZER MODULE (NEAR IGNITION LOCK CYLINDER HOUSING) TRANSMISSION CONTROL MODULE (W/ 4.7L ENGINE) (ON RIGHT INNER FENDER) VEHICLE INFORMATION CENTER VIO/ORG WIRE VIO/YEL WIRE YEL/VIO WIRE YEL/VIO/BLK WIRE YEL/VIO/BRN WIRE YEL/VIO/DK BLU WIRE YEL/VIO/DK GRN WIRE YEL/VIO/GRY WIRE YEL/VIO/ORG WIRE YEL/VIO/RED WIRE YEL/VIO/WHT WIRE
