Jeep Cherokee III (2001-2004) passenger seat temperature sensor input Wiring diagram
This page shows the only wiring diagram for the component.passenger seat temperature sensor input, which is found in the car Jeep Cherokee III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat temperature sensor input (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (ON JUNCTION BLOCK)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC JUNCTION PORT (BOTTOM OF STEERING COLUMN)
DK GRN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
DRIVER HEATED SEAT BACK
DRIVER HEATED SEAT CUSHION
DRIVER HEATED SEAT SWITCH 0 OFF 1 LOW 2 HIGH
DRIVER SEAT HEATER SWITCH MUX
DRIVER SEAT TEMPERATURE SENSOR INPUT
FUSE 20
GRN WIRE
GROUND DRIVER SEAT HEATER BATTERY (+) DRIVER
GROUND PASSENGER SEAT HEATER BATTERY (+) DRIVER
HOT IN RUN
JUNCTION BLOCK
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PANEL LAMPS DRIVER
PASSENGER HEATED SEAT BACK
PASSENGER HEATED SEAT CUSHION
PASSENGER HEATED SEAT SWITCH 0 OFF 1 LOW 2 HIGH
PASSENGER SEAT HEATER SWITCH MUX
PASSENGER SEAT TEMPERATURE SENSOR INPUT
PCI BUS
PNK 3 WIRE
PNK WIRE
SEAT HEATER SWITCH SENSOR GROUND
SEAT MODULE (UNDER DRIVER'S SEAT)
SEAT SENSER
SUPPLY
TAN WIRE
TAN/DK GRN WIRE
TAN/LT GRN WIRE
VIO WIRE
WHT WIRE
WHT/PNK WIRE
YEL WIRE
YEL/VIO WIRE
YEL/VIO/GRY WIRE
YEL/VIO/WHT WIRE
Go to component -> Heated seats circuit -> PASSENGER SEAT TEMPERATURE SENSOR INPUT
