Jeep Cherokee III (2001-2004) (near break out for 10 cavity lt grn in-line Wiring diagram
This page shows the only wiring diagram for the component.(near break out for 10 cavity lt grn in-line, which is found in the car Jeep Cherokee III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (near break out for 10 cavity lt grn in-line (1 of 1)
ADJUSTABLE PEDALS MODULE
AUTOMATIC DAY/NIGHT
BASE
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP
CONNECTOR, ABOVE LEFT REAR WHEEL HOUSING)
DRIVER POWER SEAT SWITCH
DRIVER REAR POWER WINDOW SWITCH
EXCEPT BASE
FUEL PUMP MODULE
LEFT LIFTGATE AJAR SWITCH
LEFT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH
LEFT REAR LAMP ASSEMBLY
LICENSE LAMP 1
LICENSE LAMP 2
LIFTGATE FLIP-UP AJAR SWITCH
LIFTGATE FLIP-UP RELEASE SOLENOID
MIRROR
ORG/ WIRE
OTHER
RAIN SENSOR
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT LIFTGATE AJAR SWITCH
SUN ROOF
SUN ROOF CONTROL MODULE
SUN ROOF SWITCH
SUN-ROOF MOTOR
TRAILER TOW BRAKE LAMP RELAY
TRAILER TOW CONNECTOR
TRAILER TOW LEFT TURN RELAY
TRAILER TOW RIGHT TURN RELAY
VEHICLE VEHICLE INFORMATION CENTER CENTER
Go to component -> Ground distribution circuit (2 of 4) -> (NEAR BREAK OUT FOR 10 CAVITY LT GRN IN-LINE WIRE
