Jeep Cherokee III (2001-2004) (eng harn, in breakout for crank- shaft position Wiring diagram

AUTOMATIC SHUT DOWN RELAY BLK WIRE BLK/DK GRN WIRE BLK/LT BLU WIRE BLK/RED WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (FRONT TOP OF RIGHT CYLINDER HEAD) CRANKSHAFT POSITION SENSOR (ABOVE STARTER MOTOR) CRUISE CONTROL SYSTEM DK BLU/YEL WIRE DK GRN/BLK WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DK GRN/RED WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE SENSOR (NEAR FRONT OF INTAKE MANIFOLD) ENGINE OIL PRESSURE SENSOR (ABOVE OIL FILTER) FUEL PUMP MODULE (TOP OF FUEL TANK) FUEL PUMP RELAY FUSE 12 FUSE 16 FUSE 24 FUSE 26 FUSE 6 GRY/BLK WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START INTAKE AIR TEMPERATURE SENSOR (IN INTAKE MANIFOLD PLENUM) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LT BLU/YEL WIRE LT GRN/RED WIRE MANIFOLD ABSOLUTE POSITION SENSOR (FRONT OF INTAKE MANIFOLD) NO 1 DRV NO 2 DRV NO 3 DRV NO 4 DRV ORG/ WIRE ORG/DK BLU WIRE ORG/DK GRN WIRE ORG/RED WIRE PNK/BLK WIRE PNK/WHT WIRE POWER DISTRIBUTION CENTER (AT RIGHT FRONT CORNER OF ENG COMPT, NEXT TO BATTERY) RED/DK GRN WIRE SENSOR STARTING SYSTEM TAN/BLK WIRE TAN/WHT WIRE TAN/YEL WIRE THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANSMISSION CONTROL SYSTEM TRANSMISSION SOLENOID/TRS ASSEMBLY (ON TRANSMISSION VALVE BODY) VIO/BLK WIRE VIO/WHT WIRE YEL/BLK WIRE
